Scope of Application:
Gas supply systems for large and medium steel mills
Filling of dewar bottlers
Filling of storage tanks
Other medium pressure air supply systems
Main T echnical Parameters:
Flow : 300- 35000L/h
Max outlet pressure:3.0MPa ~ 8.0MPa
Optional Configuration:
Stationary motor/Electromagnetic speed regulating machine/Variable frequency speed motor
Safety valve/Cryogenic stop valve
Gas return temperature interlocking device
Air outlet temperature interlocking device
Air outlet pressure interlocking device
Model |
Type |
Flow range L/h |
Inlet pressure MPa |
Max Outlet Pressure Mpa |
BH600-1200/30 |
Single Horizontal Piston |
600-1200 |
0.02~0.8 |
3.0 |
BH1000-3000/30 |
1000-3000 |
BH1000-2000/60 |
1000-2000 |
0.02~0.8 |
6.0 |
BH1000-3000/60 |
1000-3000 |
BH2000-4000/30 |
Double Horizontal Piston |
2000-4000 |
0.02~0.8 |
3.0 |
BH3000-6000/30 |
3000-6000 |
BH2000-4000/60 |
2000-4000 |
0.02~0.8 |
6.0 |
BH3000-6000/60 |
3000-6000 |
BH4000-8000/30 |
Triple Horizontal Piston |
4000-8000 |
0.02~0.8 |
3.0 |
BH5000-10000/30 |
5000-10000 |
BH8000-15000/30 |
8000-15000 |
BH5000-10000/60 |
5000-10000 |
0.02~0.8 |
6.0 |
BH8000-15000/60 |
8000-15000 |
BH10000-20000/30 |
10000-20000 |
0.02~0.8 |
3.0 |
BH20000-35000/30 |
20000-35000 |
